Processo
Workflow Completo
Processo operativo del compressore volumetrico SITES
flowchart TD
A[Ingresso Gas Fi
~5 bar] --> B[Aperture 39a-39b
Riempimento Camere]
B --> C[Attuatore Idraulico
Pistone Centrale 17]
C --> D[Espansione Camere
35a-35b]
D --> E[Sensore Magnetico 29
Rileva Fine Corsa]
E --> F[Valvola 27
Inverte Flusso Olio]
F --> G[Compressione
Pistoni Laterali 13a-13b]
G --> H[Gas Alta Pressione Fu
Uscita 41a-41b]
H --> I[Scambiatori 70
Alette 73a-73b]
I --> J[Raffreddamento
in Cascata]
J --> K[Liquefazione Finale
CH₄ / CO₂ / H₂]
style A fill:#94a3b8,stroke:#64748b,stroke-width:2px
style B fill:#3b82f6,stroke:#2563eb,stroke-width:3px,color:#fff
style C fill:#8b5cf6,stroke:#7c3aed,stroke-width:3px,color:#fff
style D fill:#06b6d4,stroke:#0891b2,stroke-width:2px,color:#fff
style E fill:#ec4899,stroke:#db2777,stroke-width:2px,color:#fff
style F fill:#f97316,stroke:#ea580c,stroke-width:2px,color:#fff
style G fill:#ef4444,stroke:#dc2626,stroke-width:3px,color:#fff
style H fill:#10b981,stroke:#059669,stroke-width:3px,color:#fff
style I fill:#14b8a6,stroke:#0d9488,stroke-width:3px,color:#fff
style J fill:#3b82f6,stroke:#2563eb,stroke-width:3px,color:#fff
style K fill:#22c55e,stroke:#16a34a,stroke-width:5px,color:#fff,font-weight:bold
